- Modelo:
AP-AC-PRO
- Especificações:
Weight
With Mounting Kits
350 g (12.4 oz)
450 g (15.9 oz)
Networking Interface (2) 10/100/1000 Ethernet Ports
Buttons Reset
Antennas (3) Dual-Band Antennas, 2.4 GHz: 3 dBi, 5 GHz: 3 dBi
Wi-Fi Standards 802.11 a/b/g/n/ac
Power Method Passive Power over Ethernet (48V), 802.3af/803.2at Supported
(Supported Voltage Range: 44 to 57VDC)
Power Supply 48V, 0.5A PoE Gigabit Adapter*
Maximum Power Consumption 9W
Maximum TX Power
2.4 GHz
5 GHz
22 dBm
22 dBm
BSSID Up to Four per Radio
Power Save Supported
Wireless Security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
Certifications CE, FCC, IC
Mounting Wall/Ceiling (Kits Included)
Operating Temperature -10 to 70° C (14 to 158° F)
Operating Humidity 5 to 95% Noncondensing
* Only the single-pack of the UAP-AC-PRO includes a PoE adapter.
Advanced Traffic Management
VLAN 802.1Q
Advanced QoS Per-User Rate Limiting
Guest Traffic Isolation Supported
WMM Voice, Video, Best Effort, and Background
Concurrent Clients 200+
Supported Data Rates (Mbps)
Standard Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40)
802.11ac 6.5 Mbps to 1300 Mbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80)
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- Dimensions
196.7 x 196.7 x 35 mm (7.74 x 7.74 x 1.38")
- Garantia
12 meses (9 meses de garantia contratual junto ao fabricante + 3 meses referentes à garantia legal, nos termos do artigo 26, II, do Código de Defesa do Consumidor).
